Arlu® (Argenta) Pivotica Pro E 100 FM F90
$604.00
Product Information
The Pivotica Pro E100 FM F90 is designed for ease of use, flexibility, and aesthetic appeal. It offers seamless installation with a choice of pivot points and two installation methods, making it adaptable to any project. The hinge’s adjustability ensures a perfect flush-to-wall fit, and its innovative design features, such as the magnetic axis and special mounting key, simplify the process.
With a maximum opening angle of 150° and an adjustable closing speed, this pivot hinge provides superior functionality. Its minimalist, screw-free design and matching cover plates in mat chrome, black, or white create a sleek, integrated look. Ideal for new builds and renovations, the Pivotica Pro E100 is also compatible with underfloor heating, making it a versatile and stylish solution for any architectural need. Transform your doors with this premium pivot hinge for a modern, seamless, and efficient installation.
Key Benefits:
- Sleek Appearance: Keeps doors perfectly flush with the wall, enhancing the modern look of your space.
- Child-Friendly: Designed with safety in mind, ideal for family homes.
- Convenient Operation: The active closure damper ensures doors always return to the zero position, and the optional 90° holding position eliminates the need for a doorstop.
Features:
- Quick and easy installation (surface mounted or built-in)
- Opens 150° in both directions
- Safe for underfloor heating applications
- Adjustable alignment and bottom plate
- Suitable for doors weighing 100kg and 150kg
Elevate your interior spaces with our smart, self-closing floor-mounted pivot hinges, combining style, safety, and convenience for the perfect modern home.
Specifications
|
Door weight |
Max. 100kg |
|
Door height |
Max. 3000 mm |
|
Door width |
Max. 2000 mm |
|
Door thickness |
Min. 40 mm |
|
Opening angle |
Max. 150° |
|
Fix position |
+90° / -90° |
|
Depth adjustment |
-3 / +3mm |
|
Alignment |
-4° / +4° |
Optional
- Black or white cover caps
- Active 2-speed damper
- Adjustable floor plate
|
Finishes |
EAN |
|
Matt Chrome |
91500104 |
|
White |
91500108 |
|
Black |
91500100 |
Why Choose Our Door Solutions?
- Seamless Aesthetic: Achieve a clean, modern look with concealed screws and flush fittings.
- Effortless Installation: Enjoy quick and easy setup, often by just one person, thanks to innovative design features.
Technical Documents
FAQs
Pivot hinges are a type of hinge that allows a door to pivot from a single point at the top and bottom, rather than being hinged at the side like traditional door hinges. This creates a smooth and elegant opening and closing motion.
Pivot hinges are often used in both residential and commercial settings, including modern homes, offices, hotels, and retail spaces. They are particularly popular for large, heavy doors and for creating a sleek, contemporary look.
- Aesthetic Appeal: Provides a clean and modern look with minimal visible hardware.
- Durability: Suitable for heavy doors as the weight is evenly distributed.
- Smooth Operation: Allows for a seamless and elegant opening and closing motion.
- Space Saving: Ideal for areas with limited space as they do not require a full door swing area.
- Standard Pivot Hinges: For typical doors, offering basic functionality.
- Concealed Pivot Hinges: Suitable for heavy doors as the weight is evenly distributed.
- Smooth Operation: Allows for a seamless and elegant opening and closing motion.
- Heavy-Duty Pivot Hinges: Designed for larger and heavier doors, providing extra support and stability.
- Door Size and Weight: Ensure the hinge can support the door’s dimensions and weight.
- Application: Choose a hinge type that fits the intended use (e.g., concealed for aesthetic purposes, heavy-duty for large doors).
- Smooth Operation: Allows for a seamless and elegant opening and closing motion.
- Material and Finish: Select a material and finish that matches your door and décor.
Pivot hinges can be more complex to install than traditional hinges due to the need for precise alignment and fitting. Professional installation is recommended for optimal performance and safety.
Yes, there are specific pivot hinges designed for glass doors. These hinges typically include clamps or brackets to securely attach to the glass.
Pivot hinges generally require minimal maintenance. Regularly check for any signs of wear and tear, ensure the pivot points are clean, and occasionally lubricate moving parts to ensure smooth operation.
Yes, pivot hinges can be used for exterior doors. However, it is essential to choose hinges made from weather-resistant materials to withstand outdoor conditions.
Yes, some pivot hinges are compatible with automatic door systems. Ensure that the pivot hinge and automatic system are designed to work together.
Pivot hinges are typically made from durable materials such as stainless steel, brass, or aluminum to ensure longevity and strength.
Pivot hinges can contribute to accessibility by allowing doors to open more widely and smoothly, making it easier for individuals with mobility challenges to pass through.
Contact Us
Elevate Your Interiors with the ARLU Pivotica Pro E 100
Ready to redefine modern design in your space? The ARLU Pivotica Pro E 100 offers the perfect combination of precision engineering, minimalist aesthetics, and effortless functionality. Whether you’re designing a contemporary home, a luxury commercial space, or upgrading a renovation project, this advanced pivot hinge delivers unparalleled performance and style.
With its sleek, screw-free design, magnetic axis technology, and customizable adjustments, the Pivotica Pro E 100 makes installation a breeze while ensuring your doors align flawlessly. Ideal for architects, interior designers, and joiners, this hinge transforms doors into seamless architectural elements.
Don’t just install a door—make a statement. Click now to explore the ARLU Pivotica Pro E 100 and bring your vision to life today!
